With a lightweight MAHLE hub-drive system putting out 40Nm of torque, it’s just the boost you need to head out for that lunch ride you deserve or that extra spin when your legs are feeling weary. Confluence’s aluminum frame and carbon fork are designed around geometry that puts you in a comfortable and stable position — especially important for putting in more miles at higher average speeds. Our on-bike cargo features let you bring all you need for those extra miles, and the e-assist lets you overpack without worrying about the weight penalty. Rounding it all out is SRAM’s Apex 1 drivetrain, delivering plenty of reliable gear range for wherever you point it. Charge Your Adventure with Confluence Apex 1.
Frameset
- Frame
- Confluence
- Fork
- Confluence Carbon
- Color
- Avocado Green
Drivetrain
- Drive Unit
- MAHLE X35+
- Ebike Classification
- Class 1
- Drive Type
- Hub-Drive
- Max Assist Speed
- 20mph/32kph
- Motor Torque
- 40Nm
- Range Estimate
- 40 miles
- Assist Levels
- 3
- Walk Assist
- No
- Throttle
- No
- Battery Capacity Watt Hours
- 250Wh
- Battery Type
- Li-ion
- Removable Battery
- Removable for service
- Estimated Charge Time
- 3 hours
- Charger Included
- Yes
- Lights Included
- No
- Front Derailleur
- N/A
- Rear Derailleur
- SRAM Apex 1
- Cassette
- SRAM PG-1130, 11-speed, 11–42t
- Chain
- SRAM PC-1110
- Crankset
- FSA Omega Megaexo, 40t
- Shifter
- SRAM Apex 1 x 11
- Brake Levers
- SRAM Apex
- Brake Caliper
- Tektro MD-C550
- Rotors
- Tektro R160S02M, 160mm
- Bottom Bracket
- FSA BB-4000
Components
- Headset
- FSA
- Stem
- Salsa Guide
- Handlebar
- Salsa Cowbell
- Grips/Bar Tape
- Black cork
- Seatpost
- Promax SP-2016
- Saddle
- WTB Volt
Wheels
- Front Hub
- WTB Serra
- Rear Hub
- MAHLE X35+
- Spoke
- Straight gauge, black
- Rim
- WTB ST i23, 32h
- Front Tire
- Teravail Washburn 700c x 42mm, Durable casing, wire bead
- Rear Tire
- Teravail Washburn 700c x 42mm, Durable casing, wire bead
Weight
- Complete Bike Weight
- 33 lb (57cm frame)
*Specification and pricing subject to change without notice.
